Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product Description【Input Requirements】The Y&H grid tie inverter DC input 22-60V (startup voltage 26V), Voc (solar panel) must not exceed 60V to ensure good output efficiency, Please ensure that the solar panel power is not less than 200W and check the open-circuit voltage to be between 38-60V (Voc).
【Battery Power Supply】This DC 22-60V grid tie solar inverter can only be powered by 36V/48V batteries, and when using batteries, please use a circuit breaker, The inverter features a battery discharge power mode that can automatically adjust the depth of discharge for the battery bank.
【MPPT Technology】The inverter utilizes innovative MPPT technology with an efficiency of up to 99% and a peak conversion rate of 80%. It is necessary to use solar panels of the same specifications, and the inverter comes with a limiter sensor, providing only the power required for the load. The controller wiring should not exceed 66 feet.
【LCD Display】The LCD screen can display daily power generation, total power generation, real-time grid waveform, real-time solar system voltage and current, real-time power, internal temperature, date, and time. To meet higher power usage requirements, this grid-tie inverter can be stacked, for example, using 4 grid-tie inverters stacked equals 1000W, equivalent to 4000W, with no limit on the number of stacked units.
【Output Connection Precautions】This grid-tie inverter is only suitable for connecting to the grid output and cannot directly power AC loads. Ensure correct connection of positive and negative terminals and tighten the DC terminals of the inverter to avoid loosening and short circuits. Do not use the solar controller load port to connect to the inverter.
Product DetailsBrand: | Y&H |
---|
Model #: | L2-1000W-DC22-60V-B |
---|
Size: | SUN-1000W-DC25-60V |
---|
Color: | Black |
---|
Price: | $349.99 |
---|
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionWVC series inverter Using IP65 waterproof streamline design which effectively prevent rainwater on the surface erosion. Microinverters turn the power from your solar panels into usable electricity. Single-phase microinverters are usually used in residential and small commercial environments(Support single-phase or three-phase connection)
We have improved the AC wiring solution. Configure converters for faster installation. Avoid the risk of miswiring the fire, zero and ground wires.Meanwhile, the DC input is designed with MC4 connector to avoid reversing the positive and negative terminals. (Some customers extend the solar panel cable so that the positive and negative polarity is reversed)
Grid Tie Inverter can monitor in real time the power generated by the inverter through the AC digital meter.(Voltage, current, active power, electrical energy, frequency, power factor)No fire risk and electric shock during installation and operation due to low DC voltage(up to 50V) compared with at least 200V from string inverters
Grid Tie Solar Inverter suitable for 2X250W-300W 36V solar panel (Vmp30-39V; Voc36-50V) Vmp = working voltage; Voc = open circuit voltage.Optimized for high powered 60-cell and 72-cell* modules.Each MC4 branch cannot exceed 300W
Stackable Connection;High precision phase detection;Over and under voltage protection; Over and under frequency protection; Islanding protection.Almost no maintenance work is required, clean the dust on the photovoltaic panel occasionally.
Product DetailsBrand: | Y&H |
---|
Model #: | WVC-600W-110V-LCD |
---|
Warranty: | 1 year warranty |
---|
Size: | 600W-110V-LCD |
---|
Color: | Black |
---|
Dimensions: | 11.14171 X 7.874 X 1.637792 inches (Length X Width X Height) |
---|
Price: | $139.99 (Save 6%) |
---|
Y&H 600W Solar Grid Tie Micro Inverter with AC Data Monitoring Display Screen Waterproof IP65 MPPT DC28-50V PV Input AC80-160V Output for 24V 36V Solar Panel
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product Description600W Grid Tie Inverter - MPPT Range 15-22V.【DO NOT use solar controller load ports to connect to the inverter】If you have any doubts before purchasing,please contact us immediately.We can help you choose the right machine.
Grid Tie Solar Inverter - Vmp(of a solar panel) must be in the MPPT range to ensure the good output efficiency【The grid tie inverter generates heat during operation. It is recommended to install in a ventilated, dry, and cool place. If the local weather is very hot, a small fan can be used to dissipate heat from the inverter.】
Solar Grid Tie Inverter - Fit For 12V Solar Panel 21V(Voc) 18V (Vmp)【Extension of solar panel cables. It is easy to cause the positive and negative connections to be reversed. The LED will not light up after connection.】
Solar Inverter - Max Power Point Tracking and Stackable,Island Protection【The Grid Tie inverter is equipped with banana plugs for easy connection. We have tested that the banana plugs are not firmly connected. The DC terminal will short-circuit. The instantaneous voltage will melt the DC column.】
Micro Inverter - Over Temperature Protection,Intelligent cooling fan management.If the DC connection is loose and causes a short circuit, then smoke may be emitted.The inverter adopts aluminum alloy casing, so there is no fire.
Please note: Do not use it together with a bidirectional meter in the local power grid. This is because the excess power from the inverter will be fed back into the grid, resulting in increased electricity costs. For a bidirectional power grid, we recommend using our SUN-Inverter series.
Product DetailsBrand: | Y&H |
---|
Model #: | GTI-600W-18V-110V-S |
---|
Size: | For Voc 20-24V |
---|
Color: | Silver |
---|
Dimensions: | 12.2 X 8.8 X 4.9 Inches (Length X Width X Height) |
---|
Price: | $92.99 |
---|
Y&H Grid Tie Inverter 600W Stackable DCDC15-28V PV Input AC110V MPPT Pure Sine Wave Micro Inverter fit for 12V Solar Panel/24V Battery
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionGrid Tie Inverter MPPT Range 24-42V. Vmp(of a solar panel) must be in the MPPT range to ensure the good output efficiency
Recommended Solar Panel Voltage: Vmp30-42V; Voc38-60V
Solar panel power cannot exceed 700W
Grid Tie Micro Inverter Doesn't work with battery
【 If you have any questions, you can contact us. We have professional staff to answer your questions.】
Product DetailsBrand: | Y&H |
---|
Model #: | Y&H-[other characters or numbers] |
---|
Size: | GMI-700W-110V |
---|
Color: | Black |
---|
Dimensions: | 12 X 4.9 X 2.1 inches (Length X Width X Height) |
---|
Price: | $86.99 |
---|
Y&H 700W Grid Tie Inverter MPPT Solar Input Voc34-46V AC90-140V Output for 24V 36V Solar Panel
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionGrid Tie Inverter MPPT range: 26V - 36V【DO NOT use solar controller load ports to connect to the inverter】
Solar Grid Tie Inverter-Vmp(of a solar panel) must be in the MPPT range to ensure the good output efficiency【Grid Tie Inverter cannot work, please contact Yong Hui merchant】
Grid Tie Solar Inverter-Creative MPPT technology,efficiency more than 99%【Please do not use other voltage input, for example: (20V) or(45V) Please use 200W-1000W solar panel (Voc36-46V)】
MPPT Micro Inverter-Max Power Point Tracking and Stackable,Island Protection.If the DC connection is loose and causes a short circuit, then smoke may be emitted.The inverter adopts aluminum alloy casing, so there is no fire.
Grid Tie Micro Inverter-Adopting high-frequency isolation transformer type, high efficiency 【Each time you move the inverter, tighten the DC connection terminals. Avoid short circuit of DC terminal due to loose connection】
Please note: Do not use it together with a bidirectional meter in the local power grid. This is because the excess power from the inverter will be fed back into the grid, resulting in increased electricity costs. For a bidirectional power grid, we recommend using our SUN-Inverter series.
Product DetailsBrand: | Y&H |
---|
Model #: | GTI-1000W-36V-110V-S |
---|
Size: | 24V Solar Panel Voc38-46V |
---|
Color: | Silver |
---|
Dimensions: | 13 X 6 X 3 inches (Length X Width X Height) |
---|
Price: | $125.99 |
---|
Y&H 1000W Grid Tie Inverter Stackable MPPT Pure Sine Wave DC30-45V Solar Input AC90-140V Output for 24V 30V 36V PV Panel
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionGrid Tie Inverter MPPT range: 30V - 39V.If the DC connection is loose and causes a short circuit, then smoke may be emitted.The inverter adopts aluminum alloy casing, so there is no fire.
Solar Grid Tie Inverter - Vmp(of a solar panel) must be in the MPPT range to ensure the good output efficiency
Grid Tie Solar Inverter - Creative MPPT tech makes efficiency higher than 99%. Reaction more sensitive and MPPT locking faster
Stackable Grid Tie Inverter - Parallel modular components design (Stackable use) is convenient for systems setting, flexible combination and system scalability.
Grid Tie Inversor - MPPT Function/Over Current Protection/Over Temperature Protection/Reverse Polarity Protection/Island Protection/Stackable【Y&H provides 30 days free return and 1 year warranty. If you encounter product problems, please contact the seller's support.】
Please note: Do not use it together with a bidirectional meter in the local power grid. This is because the excess power from the inverter will be fed back into the grid, resulting in increased electricity costs. For a bidirectional power grid, we recommend using our SUN-Inverter series.
Product DetailsBrand: | Y&H |
---|
Model #: | Voc34-46V |
---|
Size: | 1400W-Voc34-46V |
---|
Price: | $145.99 |
---|
Y&H 1400W Grid Tie Inverter Stackable MPPT Pure Sine Wave DC30-45V Solar Input AC110/120V Power Output fit for 24V 36V PV Panel【Voc34-46V】
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionThe MPPT range of the Grid Tie Inverter is 24-40V, and the solar panel power should not exceed 700W. Its rated output power is 650W.
For optimal output efficiency, the operating voltage Vmp (of a solar panel) must fall within the Inverter's MPPT range. We recommend Solar Panel Voltage: Vmp30-39V; Voc38-46V.
The Grid Tie Solar Inverter accommodates PV Panel Voltage: Vmp30-39V; Voc38-46V.
Please note that the power of the solar panel should not exceed 700W.
This Micro Grid Tie Inverter Doesn't work with battery.Only use solar panels as a DC power source. Package Include:1XGrid Tie Inverter.1xAC Cable.
Our 700W Grid Tie Inverter is a compact, efficient unit that converts direct current into alternating current for powering appliances or office equipment, and for connection to the utility grid. The Smart Micro Inverter ensures that its AC output is synchronized and in-phase with the utility grid.
Product DetailsBrand: | Y&H |
---|
Model #: | GMIW-700W |
---|
Warranty: | 2 |
---|
Size: | GMIW-700W |
---|
Price: | $97.99 |
---|
Y&H 700W Grid Tie Micro Inverter Auto AC110V/220V Output, DC26-46V PV Input, MPPT Pure Sine Wave, Suitable for 36V Solar Panel, Ideal for Small Home Solar Power System
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionInverters turn the power from your solar panels into usable electricity. Single-phase microinverters are usually used in residential and small commercial environments(Support single-phase or three-phase connection)
The second-generation micro-inverter :TLet you ferret out the working status of your inverter anytime and anywhere.This Smart On Grid system improves safety; maximizes solar energy harvest; increases system reliability, and simplifies solar system design, installation and management.
We have improved the AC wiring solution. Configure converters for faster installation. Avoid the risk of miswiring the fire, zero and ground wires.Meanwhile, the DC input is designed with MC4 connector to avoid reversing the positive and negative terminals. (Some customers extend the solar panel cable so that the positive and negative polarity is reversed)
Grid Tie Inverter can monitor in real time the power generated by the inverter through the AC digital meter.(Voltage, current, active power, electrical energy, frequency, power factor)No fire risk and electric shock during installation and operation due to low DC voltage(up to 50V) compared with at least 200V from string inverters
Regarding the heating problem of the inverter:this is normal phenomenon. All electronic devices generate heat during operation. The inverter uses aluminum alloy material. Metal can conduct heat better. The inverter also has over-temperature protection if the temperature is high. Then the inverter will automatically reduce the working output efficiency. Or stop working. After cooling down, restart. It is recommended to install the inverter in a ventilated, dry and cool place.
Product DetailsBrand: | Y&H |
---|
Model #: | 1200W Grid Tie Micro Inverter |
---|
Size: | 1200W-DC30-60V |
---|
Color: | black |
---|
Dimensions: | 16.141732267 X 9.842519675 X 2.755905509 inches (Length X Width X Height) |
---|
Price: | $229.99 |
---|
Y&H 1200W Grid Tie Micro Inverter Waterproof MPPT Stackable DC30-60V Solar Input AC110V 220V Auto Pure Sine Wave Output for 30V 36V PV Panel
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product DescriptionGrid Tie Inverter MPPT Range 11-21V.As the DC voltage gets closer to 11V, the inverter works less efficiently.
Vmp(of a solar panel) must be in the MPPT range to ensure the good output efficiency.
Micro grid tie inverter compatible with 12V battery. Adjustable power 80W-250W output in 12V battery mode.Low voltage battery shutdown ensures that the battery capacity is not depleted. Extends battery life.
Micro Inverter Max Power Point Tracking and Stackable,Island Protection. If the DC connection is loose and causes a short circuit, then smoke may be emitted.The inverter adopts aluminum alloy casing, so there is no fire.
Advanced Anti-island technology.LED indicators distinctively showing status of system.Simple wiring, allowing you to easily obtain clean power.
Product DetailsBrand: | Y&H |
---|
Model #: | Y&H 500W |
---|
Size: | 500W-12V-110V |
---|
Price: | $105.99 |
---|
Y&H 500W Grid Tie Inverter DC16V-28V MPPT Pure Sine Wave AC110V Output for 12V Solar Panel,Adjutable 12V Battery Discharge
Y&H 1000W Grid Tie Inverter Power Limiter DC25-60V Solar Input AC110V/240V Auto Switch
Product Description【Pure sine Wave Inverter】10200W Pure sine Wave Inverter is a new all-in-one hybrid solar inverter charger, Support dual PV input, dual MPPT voltage tracking.RGB lingthing for different working mode(Purple-PV Mode;Red-Battery Mode;Blue-Utility Mode)
【TECHNICAL SPECIFICATIONS】10.2KW Hybrid Solar Inverter Max.PV Input Power: 10200W, Voltage range: 90-450Vdc, Max.PV Input VOC: 500V DC, Starting voltage >150V; The best working voltage is 300-360V;Recommended PV cable size: 10AWG, Max. charge current: 180A. Nominal Input Frequency: 50/60Hz; Output Power: 10200W, surge Capacity: 20400W.fit for 48V Lead-Acid (Seal, AGM,Gel, Flooded) and Lithium battery
【MULTIPLE CHARGING MODES】Off Grid Solar Inverter have 4 charging modes are optional, i.e. Only Solar, Mains Frist , Solar Frist and Mains & Solar hybrid charging; and 3 output modes are available, i.e. Solar Frist, Mains Frist and SBU Priority, uninterrupted power supply to meet different application requirements. And compatible to mains voltage or generator power, Auto restart while AC is recovering.
【New features】Built-in BMS function. Lithium Battery Activation, has a reactivation feature to awaken a sleeping lithium battery. The small charge current to activate the protection circuit and if a correct cell voltage can be reached, it starts a normal charge.Dual AC output, one for the main load (UPS function), one for the conventional load.
【WIDE RANGE OF USES】MPPT Inverter Charger Pure sine Wave 10200W for RV Camping Boat Home Emergency ect.. Can be accessed to a variety of household and office loads, including Oven, rice cooker, lamps, televisions, fans and other AC loads.(Be careful not to install it near the bedroom, the fan will make a sound when the inverter is running. Avoid affecting your rest)
Note: After item 37 is set to "hyd", item 01 will jump back to SUB mode instead of SBU mode.
Product DetailsBrand: | Y&H |
---|
Model #: | MPS-MAX 10.2KW-48V-M180A |
---|
Warranty: | 12 MONTHS |
---|
Size: | 10200W-48V-M160A |
---|
Dimensions: | 21.14 X 15.35 X 5.12 inches (Length X Width X Height) |
---|
Price: | $737.99 (Save 12%) |
---|
Y&H 10.2KW On/Off Grid Solar Hybrid Inverter Built-in 160A Charge Controller PV Max 500V Input DC48V to AC230V Pure Sine Wave Inverter for Home Energy Storage RV Shed Off-Grid System
